High speed cuff packing machine
- Type
- Shrink packing machine
- Dimension(L*W*H)
- 3000(L)*1100(W)*1700(H)mm
- Voltage
- 220v/50Hz
- Production Capacity
- 15-25 bags/min
Technical Parameters
| Model | High Speed Vertical Up and Down Sealing and Cutting Machine |
| supply voltage | 220v/50Hz |
| work efficiency | 0 ~ 45/Min |
| package size | L:100-450 W:20-350 H<160mm |
| Packaging film thickness | 0.012-0.06mm |
| longitudinal cutter power | 800W |
| conveying speed | 30M/MIN |
| cross cutter heating power | 1100W |
| sealing time | 1S |
| Model | heat shrinker |
| supply voltage | 380v/50/60Hz |
| machine size | 1800x850x1380mm |
| conveyance load | 30kg max |
| Applicable shrink film | POF.PVC.PP |
| Conveying Material | chain roller |
| conveying speed | 0-15m/min |
| power | 13.2KW |
| furnace size | 1500x450x250mm |
